3. DATA CONTROL FUNCTION

B–61863E–1/06

PMC CONTROL SOFTWARE

116

NC programs can be read and registered by PMC software.

PMC software PMC control

software data

control function

NC software Hardware

CNC command

program write

data

Procedure Functions

dedicated to the NC

command program

Procedure Functions

dedicated to the NC

command program

Noncolatile

memory

CNC command

program control

CNC command

program read

data

The procedure (functions) for the NC command program is shown below.

(For details, see III-11.)

Function name Description

pl_nc_dwnstart Initiates the processing to output (download) NC command data for

registration.

pl_nc_download Outputs (downloads) NC command data for registration.

pl_nc_dwnend Terminates the processing to output (download) NC command

data for registration.

pl_nc_vrfstart Initiates the processing to output NC command data for verifica-

tion.

pl_nc_verify Outputs NC command data for verification.

pl_nc_vrfend Terminates the processing to output NC command data for verifi-

cation.

pl_nc_dncstart Initiates the processing to output NC command data for operation.

pl_nc_dnc Outputs NC command data for operation.

pl_nc_dncend Terminates the processing to output NC command data for opera-

tion.

pl_nc_search Searches for a specified NC program.

pl_nc_delall Deletes all NC programs.

pl_nc_delete Deletes a specified NC program.

pl_nc_upstart Initiates the processing to input (upload) NC command data.

pl_nc_upload Inputs (uploads) NC command data.

pl_nc_upend Terminates the processing to input (upload) NC command data.

pl_nc_dir Inputs NC program control data.

pl_nc_pdirstart Initiates the processing to input the NC program No. directory.

pl_progdir Inputs the NC program No. directory.

pl_nc_pdirend Terminates the processing to input the NC program No. directory.

3.3.2

CNC Command

Programs
