PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 419

Programming manual

Page of 619

/ 619

B–61863E–1/06

3. CREATING A C PROGRAM

APPLICATION

PROGRAMMING GUIDE

403

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

∆ ∆ f f

∆: Floating–point no supported

(1) (2) (3)

% [*] [numeric string] [l]d

[l]o

[l]x

[l]u

(1) When a “*” is specified, input data specified in this function is

skipped.

Assignment is not performed.

(2) Specifies the maximum number of digits to input of a character string.

(3) When “l” is specified, the variable is a long–type.

If not specified, the variable is a short–type.

“d” : Input as a signed decimal.

“o” : Input as an unsigned octal.

“x” : Input as an unsigned hexadecimal.

“c” : Input a single character and assign to a char–type variable.

“s” : Input a character string.

<Floating–point input> (16i/18i only)

(1) (2) (3)

% [*] [numeric string] [l]f

[l]e

[l]g

(1) When a “*” is specified, input data specified in this function is

skipped.

Assignment is not performed.

(2) Specifies the maximum number of digits to input of a character string.

(3) When “l” is specified, the variable is a double float–type.

If not specified, the variable is a float–type.

“f”, “e”, “g”: Input as a floating–point number which is composed of

one or more sequential decimal number with a sign

(+,–) and decimal point (optional), exponent(“e”) and

signed integer (optional).

3.2.4

Format Specifications

for Scanf Functions

(sscanf)

Contents Summary of PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual
