PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 494

Programming manual

Page of 619

/ 619

B. STACKING CONDITION FOR

LIBRARY FUNCTIONS

B–61863E–1/06

APPENDIX

478

Function Required stack sizeFunction name

Functions related to the reader/punch interface pl_rsopen,pl_rsclose

pl_rsrd,pl_rswrt

pl_fopen,pl_fdir,pl_fdel

pl_rsopen2, pl_rsclose2

pl_rsrd2, pl_rswrt2

pl_fopen2, pl_fdir2, pl_fdel2

Approx. 150 bytes

NC window data pl_nc_windr,pl_nc_windw

pl_exin

Approx. 120 bytes

NC command program pl_nc_dwnstart,pl_nc_download

pl_nc_dwnend,pl_nc_vrfstart

pl_nc_verify,pl_nc_vrfend

pl_nc_dncstart,pl_nc_dnc

pl_nc_dncend,pl_nc_search

pl_nc_delall,pl_nc_delete

pl_nc_upstart,pl_nc_upload

pl_nc_upend,pl_nc_dir

pl_nc_pdirstart,pl_progdir

pl_nc_pdirend

Note) TT-series ”pl_nc_***2 is the same.

Approx. 150 bytes

MMC window data pl_mmcwr,pl_mmcww

pl_mmc3r,pl_mmc3w

Approx. 100 bytes

Conversion between ASCII and ISO pl_asciso,pl_isoasc Approx. 30 bytes
