8. CRT CHARACTER DISPLAY

B–61863E–1/06

PMC LIBRARY

234

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f  f 

[Name]

pl_dsppalette

[Description]

Sets the all color palette for VGA character display.

[Format]

ret = pl_dsppalette(p1);

short ret;

long *p1

[Input]

*p1 Palette information

Color information

R value, G value and B value of the color palette are set

respectively as follows. Each value can specify from 0 to 3FH.

Please do not change the setting of palette 0 (Please always

input 0).

4 byte 3 byte 2 byte 1 byte

Always 0 B value G value R value

[Output]

______

[Returns]

ret Completion code (–1, 0)

[Remarks]

For the return value, see the item on the completion code types.

This function is effective only in VGA.

NOTE

A screen color is set on the color setting screen.

8.20

SETTING COLOR

PALETTE FOR VGA

CHARACTER

DISPLAY

Color information of palette 0 (always 0)

Color information of palette 1

Color information of palette 14

Color information of palette 15
