9. C-PROGRAM MEMORY DISPLAY

AND DEBUG FUNCTION

B–61863E–1/06

APPLICATION

PROGRAMMING GUIDE

424

This function displays the contents of GDT (Global Descriptor Table) in

order to confirm the GDT data set by a C program. This function can also

be used to dump the memory of a specified descriptor table.

Soft keys correspond to functions as follows:

NO.SRH M.DUMP

GDT USRMEM

RET

DEBUG

INPUTSEARCH

WORDBYTE D.WORD

RET

(1) Press the [GDT] soft key to display C-program GDT data on the CRT

display as shown in Figure 9.1.1(a).

(2) Press the [NO.SRH] soft key to search for a particular GDT table No.

(3) Press the [M.DUMP] soft key to dump the memory of the first GDT

No. currently displayed.

(4) Press the [NEXT] soft key on the memory dump display screen, then

press [BYTE], [WORD], or [D.WORD] to select the data type. Each

of these keys corresponds respectively to bytes (1-byte), words

(2-bytes), and double words (4-bytes). (See Figure 9.1.1(b).)

(5) When keep-relay K17/K900 bit4 = 1, the RAM contents shown on the

memory dump display screen can be modified by moving the cursor

to the data to modify and entering data of the specified data type.

WARNING

Depending on the data entered, the user program may not

operate correctly and a system error may occur. Be sure to

exercise sufficient care when setting data.

9.1

GDT INFORMATION

DISPLAY

9.1.1

Screen Display and

Operations
