3. DATA CONTROL FUNCTION

B–61863E–1/06

PMC CONTROL SOFTWARE

104

NOTE

The case of FS15i–A:

The pl_fkey_sts() function is not supported.

By using the pl_fkey_ign() and the pl_fkey_avil() function,

it is possible to protect to switch screen by function key. By

using these functions, the screen can be switched after

terminating process when a function key is pressed.

The case of FS16i /18i /21i :

By using the pl_fkey_ign(), the pl_fkey_avil() and the

pl_fkey_sts() function, it is possible to protect to switch

screen by function key.

The case of FS15B:

The pl_fkey_ign(), the pl_fkey_avil() and the pl_fkey_sts()

functions are not supported.

(2) MDI keys

When the PMCMDI screen is displayed, MDI keys can be read using

the system call, pl_mdikey. The function keys among the MDI keys,

however, cannot be read. This is because these functions keys are

normally used as the command keys to specify screen switching.

These function keys, however, can also be read if screen switching is

disabled by issuing the system call, pl_fkey_ign.

When the screen is switched to the PMCMDI screen, the MDI key

input line and the key-in line are set by the PMC control software as

follows:

For FS16i /18i /21i:

9′′ CRT 10′′ LCD, 14′′ CRT

Maximum number of input characters 40 characters 60 characters

Key-in line display Provided Provided

Key-in line 13 lines 20 lines

Prompt Not provided Not provided

To redefine the setting, use pl_keydef() function.

The above settings can be changed by the application program. To

redefine the settings, use the system call, pl_keydef.

For FS15i–A:

9.5”LCD,10.4”LCD

Maximum number of input characters 73 characters

Key–in line display Provided

Key–in line 25 lines

Prompt Non provided

It is impossible to redefine the setting.
