14. MMC WINDOW LIBRARY

B–61863E–1/06

PMC LIBRARY

362

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f f  

[Name]

pl_mmc3r

[Description]

Reads data of up to 256 bytes via the window between PMC and

MMC. The contents of data can be determined arbitrarily by the PMC

or MMC-III application program.

[Format]

ret = pl_mmc3r(buffer_no,offset,data_len,read_buffer);

short ret ;

unsigned short buffer_no,offset,data_len ;

char *read_buffer ;

[Input]

buffer_no : Specifies the buffer in which data is read.

offset : Specifies the point from which data starts to be read,

as a relative value from the beginning of the buffer.

data_len : Specifies the number of data items to be read from

MMC-III. (Up to 256 bytes)

*read_buffer : Specifies the address in which data read from

MMC-III is stored.

[Output]

Data

[Returns]

ret Complete code : –11, 0, 2, 3, or 6

–11: Initialization of the MMC-III is not completed. (The buffer is

not initialized.)

0: Normal termination

2: The specified data length is incorrect. (Data length = 0 or

negative value, or offset + data length exceeds the buffer range)

3: There is no specified buffer. (A buffer number other than 1 to

10 is specified.)

6: There is no required option. (MMC-III is not provided.)

[Remarks]

______

14.3

READING

ARBITRARY DATA

FROM MMC VIA THE

WINDOW (MMC-III)

254

255

read_buffer

Data sent from MMC-III is set.
