3. DATA CONTROL FUNCTION
B–61863E–1/06
PMC CONTROL SOFTWARE
118
Window data between the PMC and the NC can be read and written. The
window data items are listed below.
(1) Data input from the NC
Function No. Description
0 Reads CNC system information. *2
13 Reads tool offset values.
15 Reads workpiece zero point offset values.
17 Reads parameters.
154 Reads parameters.
19 Reads setting data.
155 Reads setting data.
21 Reads custom macro variables.
23 Reads CNC alarm information.
24 Reads the number of the program being executed.
25 Reads the number of the sequence being executed.
26 Reads the actual speed of the controlled axis.
27 Reads the absolute position of the controlled axis.
28 Reads the machine coordinates of the controlled axis.
29 Reads the skip position of the controlled axis.
30 Reads the servo delay of the controlled axis.
31 Reads the acceleration/deceleration delay.
32 Reads modal data.
33 Reads diagnostic data.
156 Reads diagnostic data.
34 Reads A/D converted data (from general analog data and load current of
feed motor).
38 Reads tool life management data (tool group numbers).
39 Reads tool life management data (number of tool groups).
40 Reads tool life management data (number of tools).
41 Reads tool life management data (tool life).
42 Reads tool life management data (tool life counter).
160 Reads tool life management data (tool life counter type).
43 Reads tool life management data (tool length compensation No. (1): Tool
No.).
44 Reads tool life management data (tool length compensation No. (2): Tool
use order).
45 Reads tool life management data (cutter compensation No. (1): Tool No.).
46 Reads tool life management data (cutter compensation No. (2): Tool use
order).
47 Reads tool life management data (tool information (1): Tool No.).
48 Reads tool life management data (tool information (2): Tool use order).
49 Reads tool life management data (tool No.).
50 Reads the actual spindle speed. *2
59 Reads P code macro variables.
151 Reads clock data (date and time).
153 Reads load information of the spindle motor.
154 Reads the parameter
155 Reads the setting data
156 Reads the diagnosis data
157 Reads character strings of a CNC program being executed in the buffer.
*2
74 Reads the relative position of the controlled axis.
75 Reads the remaining travel of the controlled axis.
76 Reads CNC status information. *2
83 Reads the operator message *2
3.3.4
NC Data
*1
*1
*1
*1
*1
