12. NC COMMAND PROGRAM (PMC-SC)PMC LIBRARY

323

(b) When program numbers, comments, and the number of used

memory areas are read

’O’

’1’

’(’

’P’

’R’

’O’

’G’

’1’

’)’

’2’

’5’

’6’

’O’

’1’

’2’

’3’

’4’

’(’

’)’

’1’

’2’

’%’

1) Leading 0 of the program number and used memory area data

is omitted.

2) The comment statement enclosed in parentheses ( )

immediately after the program number is set. If another

address data or EOB is stored immediately after the program

number, only parentheses ( ) are set.

Up to 48 characters including parentheses ( ) are used for a

comment statement. Comment statements exceeding this

maximum number are ignored.

3) If values other than 0 are specified for the start program

number and end program number by the program number list

data input start function, all program numbers in the specified

range are set. If 0 is specified for the start program number

and end program number, the program numbers of all

registered programs are set in ascending order.

4) ’%’ (25H) alone is set if there is no program in the range of

the specified program numbers.

P2 Number of input characters in the program number list data

N–1

Program number O0011

Comment statement (PROG1)

Used memory are=256 (characters)

Program number O1234

No comment statements

Used memory area=112 (characters)
