2. TASK CONTROL FUNCTION

B–61863E–1/06

PMC CONTROL SOFTWARE

Task C

Processing A

External motion is started

processing B

Task C

Processing

External motion

is started.

Event wait function

is issued.

Event wait release

function is issued.

External motion

PWAIT command is issued.

Task D

Processing D

NOTE

1 Event wait functions

D os_wait_sem (See Section 2.6.3.)

D os_writ_flg (See Section 2.6.4.)

D os_read_mbx (See Section 2.6.5.)

D os_read2_mbx(See Section 2.6.5.)

D os_recv_pkt (See Section 2.6.6.)

2 Event wait release functions

D os_sign_sem (See Section 2.6.3.)

D os_sign_flg (See Section 2.6.4.)

D os_puls_flg (See Section 2.6.4.)

D os_write_mbx (See Section 2.6.5.)

D os_wrt2_mbx (See Section 2.6.5.)

D os_send_pkt (See Section 2.6.6.)
