C. DIFFERENCES BETWEEN THE PMC-SC

AND THE PMC-N, AND HOW TO

MIGRATE FROM THE PMC-N/NA TO

THE PMC-SC/SC3/SC4/NB/NB2

B–61863E–1/06

APPENDIX

484

The user can invoke the task management procedure using the following

functions of the PMC-N/NA system call library:

Function name Description

PMC-N/NA PCMDI Activates the PMCMDI starter task.

PMC-RC/RC3/

RC4/NB/NB2

pl_pcmdi Indicates that the event flag of the task waiting for

a PMCMDI event is set to on.

Function name Description

PMC-N/NA NCMDI Stops the PMC starter task, and switches the

screen to the NC screen.

PMC-RC/RC3/

RC4/NB/NB2

pl_ncmdi Displays the NC screen.

Function name Description

PMC-N/NA WAIT Moves the PMC-N into the wait state.

PMC-RC/RC3/

RC4/NB/NB2

os_wait_flg Waits for the event flag to be set to on.

Function name Description

PMC-N/NA WAKEUP Moves a task in the wait state into the run state.

PMC-RC/RC3/

RC4/NB/NB2

os_sign_flg

os_puls_flg

Indicates that the event flag of the task waiting for

an event is set to on.

Function name Description

PMC-N/NA LOCK

UNLOCK

Moves a task into the locked state.

Releases the locked state.

PMC-RC/RC3/

RC4/NB/NB2

os_chng_pri Switches task levels.

C.3

TASK MANAGEMENT

PROCEDURE
