3. DATA CONTROL FUNCTION

B–61863E–1/06

PMC CONTROL SOFTWARE

122

(2) Data output to NC

Function No. Description Type *1

14 Writes tool offset values Low

18 Writes parameter data and setting data Low

22 Writes custom macro variables. Low

150 Writes program check screen data. Low

152 Writes torque limit data Low

163 Writes tool life management data (tool group num-

bers)

Low

164 Writes tool life management data (tool life) Low

165 Writes tool life management data (tool life counter) Low

166 Writes tool life management data (tool life counter

type)

Low

167 Writes tool life management data (tool length com-

pensation No.1)

Low

168 Writes tool life management data (tool length com-

pensation No.2 )

Low

169 Writes tool life management data (cutter compensa-

tion No.1)

Low

170 Writes tool life management data (cutter compensa-

tion No.2)

Low

171 Writes tool life management data (tool information

No.1)

Low

172 Writes tool life management data (tool information

No.2)

Low

173 Writes tool life management data (tool No.) Low

214 Writes tool offset data according to specified tool

number.

Low

215 Writes the superposition move command. High

216 Writes feedrate.

Low *2

202 Writes tool life management data (tool group num-

bers) (for tool number 8–digits)

Low

229 Writes tool life management data (tool length com-

pensation No.1) (for tool number 8–digits)

Low

230 Writes tool life management data (cutter compensa-

tion No.1) (for tool number 8–digits)

Low

231 Writes tool life management data (tool information

No.1) (for tool number 8–digits)

Low

323 Writes real type data in NC parameter Low

NOTE

1 High means high–speed–type and Low means low–speed–

type. Low–speed–type window requests NC to read/write a

data and waits until NC returns information. C language

control software performs exclusive control not to accept

more than one low–speed–type window function requests

at the same time.

C program and ladder program is executed independently.

So, C language control software doesn’t perform exclusive

control with low–speed–type window of ladder program.

2 The function No. 216 is executed independently in spite of

the low–speed–type. The function No.216 performs

exclusive control itself if 2 or more function is executed at

same time.

3 For details of window data, please refer to Ladder

Language Programming Manual “Appendix C. Window

Function Description (PMC–NB/NB2/NB6)”.
