2. TASK CONTROL FUNCTION

B–61863E–1/06

PMC CONTROL SOFTWARE

D To create an exclusive control type semaphore, use the system

call, os_mak2_sem. This system call specifies the owner priority

used at semaphore acquisition and whether to permit multiple

signaling.

If multiple signaling is permitted, an error does not occur when

a task acquiring a semaphore waits for the same semaphore. In

this case, the number of times the task is placed in the wait state

is counted. When signaling has been performed as many times

as the counted number, the task releases the semaphore.

Semaphore signal wait operation

D To wait for signaling of an exclusive control type semaphore, use

the system call, os_wait_sem.

D If another task has the ownership of the semaphore, the current

task is placed in the wait state.

D If the current task has semaphore ownership and multiple

signaling is enabled, the counter value is incremented.

D If the current task has ownership of the semaphore and multiple

signaling is disabled, an error code is returned.

if (sem owner = NONE) → If there is no semaphore owner

sem owner = current task → Acquiring the ownership of the semaphore

count = 1 → Setting the counter value to 1

if (owner pri < current pri) → If the priority is lower than the set value

current pri = owner pri → Changing the priority

else → If there is a semaphore owner

if (sem owner = current task)→ If the semaphore owner is the current task

if (multi signal = OK) → If multiple signaling is enabled

count++ → Incrementing the counter value

else → If multiple signaling is disabled

Error → Returning an error code

else → If the semaphore owner is another task

Wait → Entering the semaphore queue

OWNER Counter Semaphore queue

Wait (TASK A) A 1 → none

Wait (TASK B) A 1 → J

Wait (TASK C) A 1 → jJ

Wait (TASK A) A 2 → jj

Semaphore signaling

D To signal an exclusive control type semaphore, issue the system

call, os_sign_sem.

D If the task signaling the semaphore does not have ownership of

the semaphore, an error results.

D The ownership counter is decremented. When the counter

reaches 0, the task relinquishes the ownership. At this time, the

priority of the task is returned to its original value. If there are

waiting tasks, one task is selected according to the queue type, the

ownership is passed to that task, then the task is placed in the

ready state. If the priority of that task is lower than the value set

for the semaphore, the priority is increased to the set value.
