7. LOAD MODULE TRANSFER

B–61863E–1/06

APPLICATION

PROGRAMMING GUIDE

420

(1) In case of transfering a Hex file by an RS–232C

Set the serial port on the personal computer.

PC/AT

c:O> mode com1:9600,n,8,2

PC–98

a:O> speed ro 9600 b8 pn s2 none

1) Connect the serial port of the personal computer with the NC via

an RS–232C cable.

2) Press the <SYSTEM> key of the CNC.

3) Press the CNC soft keys [PMC],[I/O],[HOST],and [EXEC] in

this order.

4) Transfer a Hex file.

PC/AT

c:O> copy ”file name” com1

PC–98

a:O> copy ”file name” aux

5) Transfer is completed. Then, set LANGUAGE ORIGN on the

system parameter screen of the PMC. (Press the [SYSPRM] key)

6) Press the CNC soft keys [I/O], [F–ROM], [WRITE], [C–LANG],

and [EXEC] in this order. (The C language program is written the

F_ROM.)

(2) In case of transfer by a MEMORY card

(The MEMORY card driver is necessary for the personal computer)

1) Copy a Mem file to the MEMORY card on the personal computer.

2) The MEMORY card is connected in the CNC.

3) Press the <SYSTEM> key of the CNC.

4) Press the CNC soft keys [PMC],[I/O],[M–CARD],and [READ]

in this order.

5) Input the file name or the file noumber.

6) Press the [EXEC] key of the CNC.

7) Transfer is completed. Then, set LANGUAGE ORIGN on the

system parameter screen of the PMC. (Press the [SYSPRM] key)

8) Press the CNC soft keys [I/O], [F–ROM], [WRITE], [C–LANG],

and [EXEC] in this order. (The C language program is written the

F_ROM.)

NOTE

The number “*” shows an operation on the CNC.

[Flow of operation]

Hex file

I/O screen

(Use the RS–232C or the MEMORY card)

7.1.2

Method to Transfer a

Hex File
