12. NC COMMAND PROGRAM (PMC-SC)

B–61863E–1/06

PMC LIBRARY

320

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f  f 

[Name]

pl_nc_dir2

[Description]

Reads management data of the machining program registered in the

NC. Machining program management data includes the number of

registered programs, the number of remaining programs that can be

registered, the number of used memory areas, and the number of

remaining memory areas that can be used.

[Format]

ret = pl_nc_dir2(P1, P2);

short ret;

unsigned short P1;

short *P2;

[Input]

P1 Tool post specification

0 : System other than the TT system

1 : Tool post on side 1

2 : Tool post on side 2

[Output]

P2 Program management information

Number of registered

programs

Number of remaining programs

that can be registered

Used memory area

(Numbers of characters)

Remaining memory area that can

be used (number of characters)

[Returns]

ret Complete code: 0 or 1

0 : Reading of program management data in the NC has terminated

normally.

1 : A value other than 1 or 2 was set to specify the tool post.

[Remarks]

______

12.35

READING PROGRAM

MANAGEMENT DATA

Binary format
