6. EXECUTION FILE CREATION

B–61863E–1/06

APPLICATION

PROGRAMMING GUIDE

416

(4) Binds all tasks with the PMC library

[Bind format]

BND386 &<SMPL.CON

SMPL.CON:Bind control file

TASK1.LNK,&

TASK2.LNK,&

COMDAT.LNK,&

PMC.LIB &

OJ(SMPL.LNK) NOLO &

PR(SMPL.MP1) NAME(SMPL)

(5) Building

BLD386 SMPL.LNK OBJECT(SMPL.DAT)

BUILDFILE(SMPL.BLD)

SMPL.LNK : Bind file

SMPL.DAT : Execution format load module file

BUILDFILE(BF) : Specifies the build file

NOTE

When PRINT is not specified, it is assumed to be specified

as the default and a building results output listing

(SMPL.M92) is created.

(6) Creating a MAP file

MAP386 SMPL.DAT NOTYPECHECK

NOTYPECHECK(NOTC): Type check not performed.

NOTE

When PRINT is not specified, it is assumed to be specified

as the default and a map results output listing (SMPL.MAP)

is created.
