13.NC COMMAND PROGRAM

(PMC-NB/NB2/15i–A)

B–61863E–1/06

PMC LIBRARY

348

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

 f  f

[Name]

pl_nc_dir

[Description]

The management data of machining programs which have already

been registered in the NC can be read. The management data of the

machining programs includes the number of registered programs, the

number of programs which can be additionally registered, the size of

the memory area which has been already used, and the size of the

remaining memory area.

[Format]

ret = pl_nc_dir(P1) ;

short ret ;

short *P1 ;

[Input]

______

[Output]

P1 Program management information

Number of registered

programs

Number of programs which

can be additionary registered

Size of memory area already

used (number of characters)

Size of remaining memory

area (number of characters)

[Returns]

ret Complete code : –10, –1 or 0

–10: A function is being processed. Call the function repeatedly

until a value other than –10 is returned.

–1: The function is rejected. The completion code is returned if the

function is specified while the NC is in a background edit mode

or upload mode specified by another NC command.

0: Reading of the program management data of the NC has

terminated normally.

[Remarks]

______

13.16

INPUTTING THE

PROGRAM

MANAGEMENT DATA

Binary format
