4. DIAGNOSTIC FUNCTION

B–61863E–1/06

PMC CONTROL SOFTWARE

128

Table 4.3 User Program Error Messages (2/3)

Message Description and action to be taken

WN28 DATA SEG TYPE

ERROR

The data segment type is illegal. A wrong RENAMESEG

data segment is specified for the bind control file.

(Action to be taken)

Correct the data segment according to the segment of

the build file and link control statement.

WN29 COMMON MEM SEG

TYPE ERROR

The segment type of common memory is illegal. A wrong

RENAMESEG segment is specified for the bind control file

of common memory.

(Action to be taken)

Correct the segment according to the segment of the

build file and link control statement.

WN30 IMPOSSIBLE ALLO-

CATE MEM.

A memory area for data or stack cannot be obtained.

(Action to be taken)

Check the user GDT address of the link control state-

ment and the starting address of the code segment of

the build file. Specify the smallest possible value as the

MAX LADDER AREA SIZE system parameter. Mini-

mize the stack size of the link control statement.

WN31 IMPOSSIBLE EXECUTE

LIBRARY

The library function cannot be executed.

(Action to be taken)

Check whether an applicable model is used. Replace

the PMC system ROM with a later version.

WN32 LNK CONTROL DATA

ERROR

The link control statement (program control) contains ille-

gal data.

(Action to be taken)

Check whether the LANGUAGE ORIGIN system

parameter is set to the address of the RC_CTLNB_INIT

symbol. Re-create the link control statement.

WN33 LNK CONTROL VER.

ERROR

A link control statement data version error occurred.

(Action to be taken)

Correct the link control statement of the C program.

WN34 LOAD MODULE

COUNT OVER

The number of independent load modules exceeds 8.

(Action to be taken)

Decrease the number to 8 or less.

WN35 CODE AREA OUT OF

RANGE

The code segment area is outside RAM.

(Action to be taken)

While referencing the link map, assign the segment in

the RAM area.

WN36 LANGUAGE SIZE

ERROR (OPTION)

The size of the language area exceeds the value specified

by the option.

(Action to be taken)

Check the amount of free space, then increase the

option value.

WN37 PROGRAM DATA

ERROR (LANG.)

The language program area is invalid.

(Action to be taken)

Clear the language area. [EDIT] → [CLEAR]→

[CLRLNG] → [EXEC]

WN38 RAM CHECK ERROR

(LANG.)

A RAM check error occurred in the language program

RAM.

(Action to be taken)

Replace the RAM.

WN39 PROGRAM PARITY

(LANG.)

A parity error occurred in the language program area.

(Action to be taken)

Re–enter the language program. If the error recurs,

replace the RAM.

WN40 PROGRAM DATA

ERROR BY I/O (LANG.)

The reading of a language program was suspended.

(Action to be taken)

Re–enter the language program.
