I. CONVERSION FROM FS15B TO FS15iA

B–61863E–1/06

APPENDIX

552

When a conversion is made from PMC–NB of FS15B, a different physical

address is used by a memory access function. So, those applications that

use a physical address specification function need to be modified.

NOTE

The PMC address area can be accessed using one of two

methods. One method uses the pl_mem** function, and the

other uses pl_mem**2 (where ** represents c, s, l, uc, us, ul,

brd, or bwt). The two functions differ in address specification.

The pl_mem** function uses physical addresses for address

specification. The pl_mem**2 function uses PMC address

identification codes and each address for address

specification.

The relationship between PMC addresses and physical

addresses varies from one PMC model to another. For

compatibility among different models, the use of the

pl_mem**2 function is recommended.

I.6

PHYSICAL ADDRESS

CHANGE
