Series 15i/150i - Model B Maintenance manual Page 102

Maintenance manual
1. SCREEN INDICATIONS AND OPERATIONS
B–63785EN/01
80
Method 5 (Specifying a file number: 3)
(1) Select EDIT mode.
(2) To output periodic maintenance data, display the item setting
screen. To output the Machine menu, display the item selection
menu screen.
(3) Press address key
N
.
(4) Key in a file number.
(5) Press soft key [PUNCH].
NOTE
1 Data having an item number for which no item name is set
is not output.
2 An item which is selected from the CNC menu and set is not
output.
3 When periodic maintenance data is output to a FANUC
Handy File using method 1 for outputting set items
(specifying neither an output file name nor file number),
PMNTSTS.TXT is used as the file name.
4 When the Machine menu is output to a FANUC Handy File
using method 1 for outputting set items (specifying neither
an output file name nor file number), PMNTMCN.TXT is
used as the file name.
5 When data is to be output to a FANUC Handy File, an output
file can be specified with its file name or file number.
6 When data is to be output to a memory card, an output file
can be specified with its file name.
