3. DATA INPUT/OUTPUT
B–63785EN/01
238
Method 2
(1)Click the [PUNCH] soft key.
(2)Click the
O
address key.
(3)Key in the number of the first program to be output.
(4)Click the
,
address key.
(5)Click the
O
address key.
(6)Key in the number of the last program to be output.
(7)Click the [EXEC] soft key.
Method 3
(1)Click
O
address key.
(2)Key in the number of the first program to be output.
(3)Click the
,
address key.
(4)Click the
O
address key.
(5)Key in the number of the last program to be output.
(6)Click the [EXEC] soft key.
Method 1
(1)Click the [PUNCH] soft key.
(2)Click the [”FILE NAME] soft key.
(3)Key in the file name.
(4)Click the [FILE NAME”] soft key.
(5)Click the [(PROG#)] soft key.
(6)Key in the number of the first program to be output.
(7)Click the [,(PROG#)] soft key.
(8)Key in the number of the last program to be output.
(9)Click the [EXEC] soft key.
Method 2
(1) Click the [PUNCH] soft key.
(2) Click the [”FILE NAME] soft key.
(3) Key in the file name.
(4) Click the [FILE NAME”] soft key.
(5) Click the
O
address key.
(6) Key in the number of the first program to be output.
(7) Click the
,
address key.
(8) Click the
O
address key.
(9) Key in the number of the last program to be output.
(10)Click the [EXEC] soft key.
