Series 15i/150i - Model B Maintenance manual Page 486

Maintenance manual
APPENDIXB. ALARM LIST
B–63785EN/01
464
Number ContentsMessage
PS0595 ILL–COMMAND IN EGB MODE An illegal instruction was issued during synchronization by EGB.
(1) Slave axis was specified by G27, G28, G29, G30, G30.1, G33 and
G53 G codes.
(2) Inch/metric conversion was specified by G20 or G21 G codes.
PS0596 EGB OVERFLOW An overflow occurred during calculation of the synchronization
coefficient.
PS0597 EGB AUTO PHASE FORMAT ERROR Format error in block in which G80 or G81 was specified by EGB
automatic phase alignment
(1) R is data outside of the instruction range.
PS0598 EGB AUTO PHASE PARAMETER SETTING
ERROR
Erroneous parameter settings relating to EGB automatic phase
alignment
(1) The acceleration/deceleration parameter is invalid.
(2) The automatic phase alignment parameter is invalid.
PS0610 ILLEGAL G07.1 AXIS An axis which cannot perform cylindrical interpolation was specified.
More than one axis was specified in a G07.1 block. An attempt was
made to cancel cylindrical interpolation for an axis that was not in the
cylindrical interpolation mode.
For the cylindrical interpolation axis, set not “0” but one of 5, 6 or 7
(parallel axis specification) to parameter No. 1022 to instruct the arc with
axis of rotation (ROT parameter No. 1006#1 is set to “1” and parameter
No. 1260 is set) ON.
PS0611 ILLEGAL G–CODE USE (G07.1 MODE) A G code was specified that cannot be specified in the cylindrical
interpolation mode.
This alarm also is generated when an 01 group G code was in the G00
mode or code G00 was instructed.
Cancel the cylindrical interpolation mode before instructing code G00.
PS0618 ILLEGAL P–DATA (WHEEL WEAR COM-
PENSATION)
The P data for selecting the compensation center in grinding wheel wear
compensation is illegal.
PS0619 ILLEGAL AXIS(WHEEL WEAR COMPENSA-
TION)
A compensation axis has been changed in grinding wheel wear com-
pensation mode or compensation vector maintenance mode. Alterna-
tively, the settings in parameter Nos. 6056 and 6057 that determine the
target axes for grinding wheel wear compensation are illegal.
PS0625 TOO MANY G68 NESTING 3–dimensional coordinate conversion was specified more than twice.
Cancel 3–dimensional coordinate conversion before executing new
coordinate conversion.
PS0626 G68 FORMAT ERROR There is a format error in the 3–dimensional coordinate conversion
block. The alarm occurs in the following cases:
(1) When I, J or K is missing from the block in which 3–dimensional
coordinate conversion is specified (when the coordinate rotation
option is not available)
(2) When I, J and K specified in the block in which 3–dimensional
coordinate conversion is specified are all “0”
(3) When angle of rotation R is not specified in the block in which
3–dimensional coordinate conversion is specified
PS0645 TOO MANY G68.2 NESTING The feature coordinate system set command was issued twice or more.
To set a new feature coordinate system, cancel the old feature coordi-
nate system, then issue the set command for the new feature coordinate
system.
PS0646 G68.2 FORMAT ERROR A value of 0 is specified in the I, J, and K commands in a feature
coordinate system command block.
