Series 15i/150i - Model B Maintenance manual Page 108

Maintenance manual
1. SCREEN INDICATIONS AND OPERATIONS
B–63785EN/01
86
(1) Set parameter DSL (bit 6 of No. 0013) to 1.
(2) Display the system log screen using either of the following
procedures:
Procedure 1
Press the
SYSTEM
function key several times until the system log
screen appears.
Procedure 2
(1) Press the
SYSTEM
function key.
(2) Press the [SYSTEMLOG] soft key.
Either of the following screens appears:
When the system log screen is displayed for the first time after
power–on: First page of the latest system log
When the screen is redisplayed: Previously displayed screen
The previous or next page can be displayed using the
PAGE
or
PAGE
page
switch key.
The two most recent system logs are saved. To change the displayed
system log, select the desired system log using the [LOG (NEW)] or
[LOG (OLD)] soft key.
NOTE
If no system log has been saved into backup memory, the
message “NO LOG DATA” is displayed. If the data in
backup memory is invalid, the message “CAN NOT DISP
LOG DATA” is displayed.
Procedure 1 (specifying neither an output file name nor file number)
(1)Press the [PUNCH] soft key.
(2)Press the [LOG (NEW)], [LOG (OLD)], [ALL], or [THIS DATA]
soft key.
Procedure 2 (specifying an output file name)
(1)Press the [PUNCH] soft key.
(2)Press the [“FILE NAME] soft key.
(3)Key in a file name.
(4)Press the [FILE NAME”] soft key.
(5)Press the [LOG (NEW)], [LOG (OLD)], [ALL], or [THIS DATA]
soft key.
1.12.2
Procedures
Displaying the system
log screen
D Page switch
D Selecting a system log
Outputting a system log
Previous page
Next page
