Series 15i/150i - Model B Maintenance manual Page 267

Maintenance manual
B–63785EN/01
3. DATA INPUT/OUTPUT
245
Method 3 (the file number is specified, one of three methods)
(1)Click the [PUNCH] soft key.
(2)Click the [(FILE#)] soft key.
(3)Key in the file number.
(4)Click the [TOOL OFFSET] soft key.
Method 4 (the file number is specified, one of three methods)
(1)Click the [PUNCH] soft key.
(2)Click the
N
address key.
(3)Key in the file number.
(4)Click the [TOOL OFFSET] soft key.
Method 5 (the file number is specified, one of three methods)
(1)Click the
N
address key.
(2)Key in the file number.
(3)Click the [PUNCH] soft key.
NOTE
When method 1 (in which neither the output file name nor
number need be specified), described in “Output of tool
offset data,” is used to output tool offset data to a FANUC
Handy File and Memory card, the file name will be
TOOL–OFS.TXT.
(1)Enter MDI mode.
(2)Follow either of the procedures described below to display the macro
variable screen:
Method 1
Press the
OFFSET
SETTING
function key several times, until the macro variable
screen appears.
Method 2
(1)Press the
OFFSET
SETTING
function key.
(2)Click the [MACRO VAR.] soft key.
Method 1 (neither the output file name nor number need be specified)
(1)Click the [PUNCH] soft key.
(2)Click the [COMMONNONVOL] soft key.
3.2.6
Output of Custom
Macro Variables
Setup for output
Executing output
