Series 15i/150i - Model B Maintenance manual Page 294

Maintenance manual
3. DATA INPUT/OUTPUT
B–63785EN/01
272
(1)Enter EDIT mode.
(2)Follow either of the procedures described below to display the
maintenance information screen:
Method 1
(1)Press the
SYSTEM
function key several times, until the
maintenance information screen appears.
(2)If the screen is in Japanese–language display mode, change the
input mode to single–byte alphanumeric mode.
Method 2
(1)Press the
SYSTEM
function key.
(2)Click the [MAINTEINFO] soft key.
(3)If the screen is in Japanese–language display mode, change the
input mode to single–byte alphanumeric mode.
Method 1 (neither the input file name nor number need be specified)
(1)Click the [READ] soft key.
(2)Click the [MAINTEINFO] soft key.
Method 2 (the input file is specified with its file name)
(1)Click the [READ] soft key.
(2)Click the [”FILE NAME] soft key.
(3)Key in the file name.
(4)Click the [FILE NAME”] soft key.
(5)Click the [MAINTEINFO] soft key.
Method 3 (the input file is specified with its file number, one of three
methods)
(1)Click the [READ] soft key.
(2)Click the [(FILE#)] soft key.
(3)Key in the file number.
(4)Click the [MAINTEINFO] soft key.
Method 4 (the input file is specified with its file number, one of three
methods)
(1)Click the [READ] soft key.
(2)Click the
N
address key.
(3)Key in the file number.
(4)Click the [MAINTEINFO] soft key.
Method 5 (the input file is specified with its file number, one of three
methods)
(1)Click the
N
address key.
(2)Key in the file number.
(3)Click the [READ] soft key.
3.2.28
Input of Maintenance
Information
Setup for input
Executing input
Previous page
Next page
