Series 15i/150i - Model B Maintenance manual Page 181

Maintenance manual
B–63785EN/01
2. 15i SERIES HARDWARE
159
Model Name Drawing number Remarks
FS150i
MDI unit with 56 keys (vertical
type) for 10.4″
A02B–0261–C153#MCR English key
MDI unit with 56 keys
(horizontal type) for 10.4″
A02B–0261–C154#MCR English key
MDI unit with 56 keys (vertical
type) for 10.4″
A02B–0261–C153#MCS Symbolic key
MDI unit with 56 keys
(horizontal type) for 10.4″
A02B–0261–C154#MCS Symbolic key
MDI unit with 61 keys (vertical
type) for 10.4″
A02B–0261–C163#MCR English key
MDI unit with 61 keys
(horizontal type) for 10.4″
A02B–0261–C164#MCR English key
MDI unit with 61 keys (vertical
type) for 10.4″
A02B–0261–C163#MCS Symbolic key
MDI unit with 61 keys
(horizontal type) for 10.4″
A02B–0261–C164#MCS Symbolic key
MDI unit with 56 keys (vertical
type) for 12.1″
A02B–0261–C155#MCR English key
MDI unit with 56 keys
(horizontal type) for 12.1″
A02B–0261–C156#MCR English key
MDI unit with 56 keys (vertical
type) for 12.1″
A02B–0261–C155#MCS Symbolic key
MDI unit with 56 keys
(horizontal type) for 12.1″
A02B–0261–C156#MCS Symbolic key
MDI unit with 61 keys (vertical
type) for 12.1″
A02B–0261–C165#MCR English key
MDI unit with 61 keys
(horizontal type) for 12.1″
A02B–0261–C166#MCR English key
MDI unit with 61 keys (vertical
type) for 12.1″
A02B–0261–C165#MCS Symbolic key
MDI unit with 61 keys
(horizontal type) for 12.1″
A02B–0261–C166#MCS Symbolic key
Model Name Drawing number Remarks
FS15i/150i Hard disk unit A02B–0261–C174/A
D Stand–alone type MDI
unit
2.4.6
Data Server Hard Disk
Unit
