2.MEASUREMENT CYCLE B-63874EN-1/02

- 100 -

- FEED BACK RANGE (±

±±

±)

If an offset obtained from measurement is not within the OK range

but is within this feedback range, the offset is set in the setting

destination.

If an offset obtained from measurement exceeds the feedback range,

an alarm is issued.

Enter a numeric value.

NOTE

Two stylus ball offsets are set in the calibration

data: one in the first axis direction, and the other in

the second axis direction. So, the offsets obtained

from measurement are compared in the two

directions.

If one of the offsets exceeds the feedback range,

an alarm is issued, and no setting is performed in

the calibration data.

If one of the two offsets exceeds the OK range, and

is within the feedback range, and the other is within

the OK range, the former measurement result only

is set in the calibration data.

Processing when the OK range and the feedback range are 0

The same processing as for "Touch Sensor Position Measurement" is

performed.
