2.MEASUREMENT CYCLE B-63874EN-1/02

- 148 -

β: Value of "ESCAPING DISTANCE FOR 1ST

MEASUREMENT" in the measurement condition of the group

number specified in "MEASUREMENT COND."

ε: Value of "ESCAPING DISTANCE FOR 2ND

MEASUREMENT" in the measurement condition of the group

number specified in "MEASUREMENT COND."

γ: Value of "OVERLAP DISTANCE FOR MEASUREMENT" in

the measurement condition of the group number specified in

"MEASUREMENT COND."

r: Value obtained by dividing ("STYLUS BALL 1ST AXIS

DIAMETER" in the calibration data of the group number

specified in "MEASUREMENT COND.") by 2

Motion depending on the number of measurement points

Same as for "Outside Diameter Measurement"

Motion when spindle orientation is enabled

Same as for "Outside Diameter Measurement"

G code format

When you press the INSERT key after entering necessary data, a G

code program in the following format is stored in the machining

program memory:

G2024 Q D

H V L R F P M W I J S Y

U A B K E ;

Measurement result

When G2024 is executed, the center of the circle is found from the

measured value, and is output to macro variables for the result of

measurement and as a specified workpiece origin offset value.
