2.MEASUREMENT CYCLE B-63874EN-1/02

- 242 -

2.9.3 End Face (Z-axis Direction) Measurement

The position of an end face in the Z-axis direction is measured.

When you select "Z-AXIS DIRECTION MEASUREMENT (PROBE

X-AXIS) on the post-machining inspection menu selection screen of

the measurement cycle, the following screen appears:

Measurement motion screen

As the window title, "Z-AXIS DIRECTION MEASUREMENT

(PROBE X-AXIS)" is indicated.

The other displayed items are the same as for "Z-AXIS DIRECTION

MEASUREMENT (PROBE Z-AXIS)".

The detailed descriptions of the input items are the same as for "Z-

AXIS DIRECTION WORK SETUP (PROBE X-AXIS)".

Input screen for automatic tool offset value setting

The displayed items are the same as for "Z-AXIS DIRECTION

MEASUREMENT (PROBE Z-AXIS)".

Measurement motion

The description of motion is the same as for "Z-AXIS DIRECTION

WORK SETUP (PROBE X-AXIS)".

G code format

When you press the INSERT key after entering necessary data, a G

code program in the following format is stored in the machining

program memory:

G2142 Q

P H V L R F W I S Y U J K E ;

Measurement result

When G2142 is executed, the compensation value obtained from the

measured value is output to macro variables for the result of

measurement and as a specified tool offset value.
