B-63874EN-1/02 A.PARAMETERS

- 299 -

12390 Orientation M code for positioning the spindle at 0°

(Default value = 0)

12391 Orientation M code for positioning the spindle at 90°

(Default value = 0)

12392 Orientation M code for positioning the spindle at 180°

(Default value = 0)

12393 Orientation M code for positioning the spindle at 270°

(Default value = 0)

[Data type] Two-word

[Valid data range] 0 to 99999999

12394 User program called in making manual tool measurements

(Default value = 0)

12395 User program called in making manual workpiece measurements

(Default value = 0)

12396 User program called in making automatic tool measurements

(Default value = 0)

12397 User program called in making automatic workpiece measurements

(Default value = 0)

[Data type] Two-word

[Valid data range] 0 to 9999

Number +0 is called at the start of measurement, and number +1 is

called at the end of measurement.

NOTE

If an alarm condition occurs during measurement,

no measurement-end program is called.
