2.MEASUREMENT CYCLE B-63874EN-1/02

- 88 -

- Measurement of the touch sensor position for measurement in the -Y-axis direction

<1> A rapid movement is made from the current position to the

approach point (X coordinate,Y coordinate).

Here, the approach point (X coordinate) represents the touch

sensor position Ax. The approach point (Y coordinate)

represents (touch sensor position Ay + "CLEARANCE").

<2> In the Z-axis direction, a rapid movement is made to the

approach point (Z coordinate).

The approach point (Z coordinate) represents the touch sensor

position Az.

<3> In the range from the approach point to ("CLEARANCE" + γ), a

measurement is made at feedrate f. (First measurement)

<4> Next, a rapid return movement is made by β, and a measurement

is made in the range from that position to (β + γ) at the specified

feedrate F. (Second measurement)

<5> Then, a rapid return movement is made by ε in the +Y-axis

direction.

G code format

When you press the INSERT key after entering necessary data, a G

code program in the following format is stored in the machining

program memory:

G2000 P Q

B R K H V L C F W I S Y ;

Measurement result

When G2000 is executed, the result of measurement is output to

macro variables for the result of measurement and as the touch sensor

position in the calibration data of the specified measurement

condition.
