- SETTING DEST. (T)

Specify a tool offset item in which the result of measurement is to be

set. Select a desired item from the following soft keys:

NOTE

When the tool geometry and wear compensation

options are enabled, and a compensation value

obtained from measurement is set as a tool

geometry compensation value, the tool wear

compensation value is set to 0. When a

compensation value obtained from measurement is

set as a tool wear compensation value, the

differential between the original tool geometry

compensation value and the compensation value

obtained from measurement is set.

- OK RANGE (±)

Specify an allowable range of errors obtained from measurement.

If the difference between the obtained result of measurement and the

currently set offset value (sum of a geometry compensation value and

wear compensation value) is within this allowable range, the absence

of errors is assumed, and no setting is performed in the calibration

data.

Enter a numeric value.

- FEED BACK RANGE (±)

If an error obtained from measurement is not within the OK range but

is within this feedback range, the measured value is set in the setting

destination.

If an error obtained from measurement exceeds the feedback range, an

alarm is issued.

OK RANGE AND FEEDBACK RANGE COMPARISON TARGET

If a value other than [INPUT+] and [INPUT-] is entered in "SPECIFY

OF X, Y, or Z SHIFT", a decision is made by comparing the offset

value currently set as the tool offset value with the result of

measurement.

If [INPUT+] or [INPUT-] is entered in "SPECIFY OF X, Y, or Z

SHIFT", a decision is made by comparing the value entered in

"OFFSET/DIFFERENCE X, Y or Z" with the result of measurement.

NOTE

In order to set the result of measurement as the tool

offset value at all times, enter 0 in OK RANGE, and

enter a sufficiently large value in FEED BACK

RANGE.
