B-63874EN-1/02 C.CUSTOMIZATION BY THE MACHINE TOOL BUILDER

- 307 -

C.1.2 Customization for Performing Tool Change from the Tool

Measurement Screen for Manual Measurement

To change the tool when the [TL-SEL] soft key is pressed on the tool

selection screen, create a P-CODE macro program to be called for

tool change.

Tool number

"TOOL NO." entered on the "T-SELECT" screen is stored in the

following variable:

#(value of parameter No. 12383 + 0) Tool number T entered on the screen

Tool change mechanism

When the [TL-SEL] soft key is pressed, the PMC signal for tool

change is turned on, and the user program for tool change specified in

the following parameter is activated:

12387 Macro program number for tool selection execution

(Default value = 3800)

The procedure used until the macro program for tool change is

activated after the PMC signal is turned on is the same as for manual

measurement. For details, see "Procedure for executing the macro

program for measurement execution" described in Section C.1.1.
