2.MEASUREMENT CYCLE B-63874EN-1/02

- 230 -

α: Value of "APPROACH DISTANCE FOR 1ST

MEASUREMENT" in the measurement condition of the group

number specified in "MEASUREMENT COND."

β: Value of "ESCAPING DISTANCE FOR 1ST

MEASUREMENT" in the measurement condition of the group

number specified in "MEASUREMENT COND."

γ: Value of "OVERLAP DISTANCE FOR MEASUREMENT" in

the measurement condition of the group number specified in

"MEASUREMENT COND."

ε: Value of "ESCAPING DISTANCE FOR 2ND

MEASUREMENT" in the measurement condition of the group

number specified in "MEASUREMENT COND."

r: Value obtained by dividing ("STYLUS BALL 1ST AXIS

DIAMETER" in the calibration data of the group number

specified in "MEASUREMENT COND.") by 2

G code format

When you press the INSERT key after entering necessary data, a G

code program in the following format is stored in the machining

program memory:

G2125

P Q D H V L R F W I S Y U J K

E ;

Measurement result

When G2125 is executed, the center of the projection width is found

from the measured value, and is output to macro variables for the

result of measurement and as a specified workpiece origin offset

value.
