Manual Guide i Operators manual Page 407

Operators manual
Ed.
Date
Design
Description
Name
Draw.
FANUC MANUAL GUIDE i
(Series16i/18i/21i-MB/TB)
OPERATOR’S MANUAL
B-63874EN-1/02-3
Page
FANUC LTD.
62
/
64
is exceed from a feedback range, it alarm out.
(NOTE) On a CNC for machining center, “Tool M” screen is not displayed.
Relation to Conventional Function
This function is available with Parameter No.27220#5=1. This function is
unavailable when a parameter No.27222#7= 1. When parameter
No.27220#5=0, slat Angle cannot be set as conventional version.
Measurement Operation
<1> Operate measurement perpendicular direction to angle entered from a
current point. At 1
st
point measurement, +X axis direction is set to 0°,
and operate to direction of smaller angle. Move to “center point ”
+(“protrude width” /2+α+r) of right angle direction of protrude by rapid
feed rate.
<2> Move to approach point (point of “height of measurement position” +
“approach distance”) for Z axis direction by rapid feed rate.
<3> Move to a point specified at “Height of measurement position” to –Z
axis direction by feed rate Fb, and from that point measure for a range
from approach point to (α＋γ－Stylus Radius r ) by federate f. (1
st
measurement)
<4> Then, return for β by rapid federate, and measure for a range from
the returned point to (β＋γ) by specified federate at measurement .
(2
nd
measurement)
<5> After that, return forε by rapid feed rate, and return Z axis to
approach point (“height of measurement position” + “Approach
distance”) by Z axis direction.
<6> After that, move to center point by rapid feed rate, and move to an
approach point of minus side by feed rate Fa. Operate the same
measurement to －X（－Y）axis direction.
G code Type
After enter the required data, press INSERT key to memory a G code type
program as below to machining program memory.
G2045 Q_ D_ H_ V_ M_ L_ R_ F_ W_ T_ X_ B_ I_ S_ Y_ U_ C_ Z_ A_ J_
K_ E_ ;
Measurement Result
Operate G2045 to output a measurement result to specify tool offset
amount.
7.5.1.4 Other Measurement cycles
Other measurement is the same.
