FANUC MANUAL GUIDE i
(Series16i/18i/21i-MB/TB)
OPERATOR’S MANUAL
B-63874EN-1/02-3
Page
FANUC LTD.
48
/
64
T-VARIABLE
Input Item Meaning
W MACRO
VARIABLE
Macro variable number for which the result of
measurement is to be set. The value setting in the
parameter No.27246 is displayed as a default data.
X Center X of
Rotation
Set center X of rotation for coordinate system rotation.
Z Center Y of
Rotation
Set center Y of rotation for coordinate system rotation.
S OK RANGE (±) Allowable range of errors obtained from measurement.
Y FEED BACK
RANGE (±)
If an error obtained from measurement is not within
the OK range but is within this feedback range, the
measured value is set in the setting destination. If an
error obtained from measurement exceeds the feedback
range, an alarm is issued.
(NOTE) With the CNC for a machining center, the “T-VARIABLE” screen is
not displayed.
M-VARIABLE
Input Item Meaning
U MACRO
VARIABLE
Macro variable number for which the result of
measurement is to be set. The value setting in the
parameter No.27246 is displayed as a default data.
I Center X of
Rotation
Set center X of rotation for coordinate system rotation.
J Center Y of
Rotation
Set center Y of rotation for coordinate system rotation.
K OK RANGE (±) Allowable range of errors obtained from measurement.
E FEED BACK
RANGE (±)
If an error obtained from measurement is not within
the OK range but is within this feedback range, the
measured value is set in the setting destination. If an
error obtained from measurement exceeds the feedback
range, an alarm is issued.
(NOTE) With the CNC for a lathe, the “M-VARIABLE” screen is not
displayed.
Coordinate Rotation
When the parameter No.27220#2 is 1, the coordinate system rotation is
automatically executed by measurement angle after finishing measurement.
