B-63874EN-1/02 C.CUSTOMIZATION BY THE MACHINE TOOL BUILDER

- 305 -

C.1 CUSTOMIZATION FOR OPERATING THE SET-UP

GUIDANCE FUNCTIONS

When using the measurement functions, each machine tool builder

needs to perform customization as described below. This

customization work is required even when the FANUC standard

measurement functions are used.

C.1.1 Customization for Operating Manual Measurement

For manual measurement operation, a PMC program used to start the

operation of the macro program for measurement execution needs to

be created.

Procedure for executing the macro program for measurement execution

When the [MESURE] soft key is pressed on the manual measurement

screen, the macro program for measurement execution is executed for

measurement according to the procedure below.

<1> The MANUAL GUIDE system software turns on the user

program execution start signal (GST).

<2> After the MEM mode is set, the PMC program turns on the

automatic operation start signal.

<3> The macro program for measurement execution set in the

parameter indicated below is executed.

<4> Upon completion of program operation, the PMC program turns

on the user program execution end signal (GERS).

User program number for measurement execution

Specify a user program (P-CODE macro program) for

measurement execution in the following parameter:

12388 Macro program number for measurement execution

(Default value = 3600)

Modification to the PMC program

<1> Execution start processing at user program call time

When the [MESURE] soft key is pressed on the measurement

execution screen, the MANUAL GUIDE system software sets bit

0 (hereinafter referred to as "GST") of the R signal specified in

parameter No. 12386 to 1 to start the execution of the called

program.

GST=1: Requests the start of execution after switching the mode

to the MEM mode.

In response to the request above, the PMC program must switch

the mode to the NEM mode, then perform processing for starting

machining operation.
