2.MEASUREMENT CYCLE B-63874EN-1/02

- 216 -

The symbols used above have the following meanings:

f: Value of "FEED-RATE FOR 1ST MEASUREMENT" in the

measurement condition of the group number specified in

"MEASUREMENT COND."

β: Value of "ESCAPING DISTANCE FOR 1ST

MEASUREMENT" in the measurement condition of the group

number specified in "MEASUREMENT COND."

γ: Value of "OVERLAP DISTANCE FOR MEASUREMENT" in

the measurement condition of the group number specified in

"MEASUREMENT COND."

G code format

When you press the INSERT key after entering necessary data, a G

code program in the following format is stored in the machining

program memory:

G2120 Q

P H V L R F W I S Y U J K E ;

Measurement result

When G2120 is executed, the result of measurement is output to

macro variables for the result of measurement and as the X coordinate

of a specified workpiece origin offset value.
