2.MEASUREMENT CYCLE B-63874EN-1/02

- 136 -

Measurement motion

<1> A rapid movement is made from the current position to the

approach point (X coordinate,Y coordinate).

Here, the approach point (X coordinate) is the same as

"MEASURE POINT X".

The approach point (Y coordinate) represents ("MEASURE

POINT Y" – APROCH DISTANCE) when the measurement

direction is "+Y", or the approach point (Y coordinate)

represents ("MEASURE POINT Y" + APROCH DISTANCE)

when the measurement direction is "-Y".

Other motions are the same as for "X-AXIS DIRECTION WORK

SETUP (PROBE Z-AXIS)".

G code format

When you press the INSERT key after entering necessary data, a G

code program in the following format is stored in the machining

program memory:

G2021 Q

P H V L R F W I S Y U J K E ;

Measurement result

When G2021 is executed, the result of measurement is output to

macro variables for the result of measurement and as the Y coordinate

of a specified workpiece origin offset value.
