B.ALARMS B-63874EN-1/02
- 302 -
Alarm No. Description
Cause An unauthorized attempt was made to access a macro variable.
3178
Measure
Make sure that the number set for a macro variable used with the set-up guidance function
is correct. (Parameter Nos. 12381 to 12385).
Cause An unauthorized attempt was made to access a parameter.
3179
Measure
Make sure that the parameters set for the set-up guidance and tool management functions
are correct.
Cause An unauthorized attempt was made to access a tool offset value.
3180
Measure Make sure that the offset value for a specified tool can be read and written normally.
Cause The specified tool number was not found.
3181
Measure Check the tool number entered as a feedback destination.
Cause The specified group number was not found.
3182
Measure Check the group number entered as a feedback destination.
Cause The value specified in parameter No.14825 is incorrect.
3183
Measure Make sure that the value specified in parameter No.14825 is correct.
Cause The specified offset type is incorrect.
3184
Measure Check the offset type entered as a feedback destination.
Cause An offset number and an offset type were specified at the same time.
3185
Measure
Make sure that the offset number and an offset type have not been specified at the same
time.
Cause A tool number and a group were specified at the same time.
3186
Measure
Make sure that the tool and group numbers have not been specified as a feedback
destination at the same time.
Cause System error: Control command
3187
Measure
If this alarm is issued, it is likely that there may be a problem in the system. Inform FANUC
of this alarm number and the contents of the machining program that encountered the
alarm.
Cause A tool number is invalid.
3188
Measure Check the tool number entered as a feedback destination.
Cause A group number is invalid.
3189
Measure Check the group number entered as a feedback destination.
Cause An offset type is invalid.
3190
Measure Check the offset type entered as a feedback destination.
Cause System error: T/M
3191
Measure
If this alarm is issued, it is likely that there may be a problem in the system. Inform FANUC
of this alarm number and the contents of the machining program that encountered the
alarm.
Cause System error: Setting destination
3192
Measure Check the setting destination entered as a feedback destination.
Cause System error: Setting condition
3193
Measure Check the setting condition entered as a feedback destination.
Cause An offset number is invalid.
3194
Measure Check the offset number entered as a feedback destination.
Cause System error: Variable
3195
Measure
If this alarm is issued, it is likely that there may be a problem in the system. Inform FANUC
of this alarm number and the contents of the machining program that encountered the
alarm.
Cause System error: Memory
3296
Measure
If this alarm is issued, it is likely that there may be a problem in the system. Inform FANUC
of this alarm number and the contents of the machining program that encountered the
alarm.
Cause The value set as the tool offset failed to fall in the allowable range.
3297
Measure Check the maximum tool wear offset value specified in NC parameter No. 5013.
