3. αiS/αiF/βiS SERIES PARAMETER ADJUSTMENT B-65270EN/05

- 104 -

3.3.6 Stick Slip

When the time from the detection of a position error until the

compensation torque is output is too long, a stick slip occurs during

low-speed feed. Improvement in gain is required. However, for a

machine with high friction and torsion, a higher gain cannot be set. In

such a case, a stick slip phenomenon may occur.

(Reference: Parameter numbers)

For details, see Chapter 4, "SERVO FUNCTION DETAILS."

Function 1: VCMD offset function

#7 #6 #5 #4 #3 #2 #1 #0

1808 (FS15i)

VOFS

2003 (FS30i, 16i)

VOFS (#7) 1: Enables the VCMD offset function.

1857 (FS15i)

Incomplete integral gain

2045 (FS30i, 16i)

<1> Adjust the position gain and velocity loop gain

according to the description in Subsec. 3.3.1.

<4> Set the VCMD offset function. (Function 1)

<2> Set PI function.

<3> To improve torque start, increase the velocity

loop integral gain.

<5> Set the incomplete integral coefficient within the

range 32700 to 32767 (function 2). For axes subject

to interpolation, this coefficient must not be set.
