B-65270EN/05 APPENDIX I.SERVO CHECK BOARD OPERATING PROCEDURE

- 517 -

I SERVO CHECK BOARD OPERATING

PROCEDURE

(1) Overview

The servo check board enables digital control values used in a digital

servo section to be observed from the outside. The digital control

values can be observed in either analog or digital form. Analog

outputs can be observed directly with an oscilloscope, and digital

outputs can be observed with a personal computer.

(2) Servo check board configuration

The following table lists the signals that can be observed with the

servo check board, and the number of supported axes.

Table I (a) Servo check board specification

Name Specification Output interface

Number of

supported

axes

Number of

output

channels

A A06B-6057-H630 Analog and digital 8 4 (optional)

B A06B-6057-H620 Digital only 4 4 (optional) (*)

C A06B-6057-H602 Analog only 2 8 (fixed) (*)

* Servo check board A (one-piece analog/digital type) is

upward-compatible, that is, can be replaced, with digital check

board B and analog check board C.

The method for connecting the servo check board with a CNC varies

with the type of the CNC.

The method may also vary with the name of a connectable terminal.

The following table lists the ordering information for adapters and

cables required to connect the check board.

Table I (b) Adapters and cables required to connect the servo check

board to each CNC

CNC

Required adapters and

cables

Ordering

information

Series 16i, 18i, 21i, 0i Dedicated i-B adapter board

+ dedicated i-B cable

Straight cable

A02B-0281-K822

A06B-6050-K872

Series 15i, Power Mate i

Adapter board

+ dedicated i series cable

Straight cable

A02B-0236-K822

A06B-6050-K872

NOTE

With the Series 30i, 31i, and 32i, the check board

cannot be connected.
