G.PARAMETERS FOR α AND OTHER SERIES APPENDIX B-65270EN/05

- 478 -

G.2 MOTOR NUMBERS OF β SERIES MOTORS

β series servo motor

Motor model

Motor

specification

Motor ID No. 90B0 9096

β0.5/3000 0113 14 (20-A driving) N D

β1/3000

0031 11 (20-A driving) N D

β2/3000 0032 12 (20-A driving) N D

β3/3000 0033 33 A A

β6/2000

0034 34 A A

The motor ID numbers are for servo HRV1.

βM series servo motor

Motor model

Motor

specification

Motor ID No. 90B0 9096

βM0.2/4000 0111 * (260) N *

βM0.3/4000

0112 * (261) N *

βM0.4/4000 0114 * (280) N *

βM0.5/4000 0115 181(281) N D

βM1/4000

0116 182(282) N D

The motor ID numbers not enclosed in parentheses are for servo

HRV1, and the motor ID numbers enclosed in parentheses are for

servo HRV2 and HRV3.

* For βM0.2, βM0.3, and βM0.4, HRV1 control cannot be used. It

cannot, therefore, be used in Series 9096.

(Reference)

In the parameter table in item 4, two motor ID numbers are

assigned to the same β series servo motor. One of them is the

parameter for driving the motor with an α/β series servo

amplifier (12A). Use caution not to use the wrong type number.

α servo amplifier drive

αi servo amplifier drive

Motor model

Maximum

amplifier

current [A]

Motor ID No.

Maximum

amplifier

current [A]

Motor ID No.

β0.5/3000 12 13 20 14

β1/3000 12 35 20 11

β2/3000 12 36 20 12
