B-65270EN/05 4.SERVO FUNCTION DETAILS

- 279 -

[Small motors] (pole-to-pole span: 30mm)

FFG(No.2084/No.2085)

Signal pitch

PLC0

(2000#0)

Number of velocity pulses /

Number of position pulses,

Conversion coefficient

(No.2023 / No.2024, 2185)

AMR conversion

coefficient 1 or 2

(No.2112, 2138)

1-µm detection

0.1-µm

detection

20 0 5000 / 16000, 0 1500, 9 5 / 128 50 / 128

40 0 2500 / 8000, 0 750, 9 5 / 64 50 / 64

2 1 5000 / 8000, 2 15000, 9 1 / 256 10 / 256

4 1 2500 / 8000, 0 7500, 9 1 / 128 10 / 128

40.513167 0 2468 / 7899, 0 1481, 8 301 / 3804 3010 / 3804

* The parameter Nos. for the Series 15i are omitted. See the

previous page.

Table 4.14.1 (e) Parameter setting when an absolute type linear encoder is used

[Medium-size and large motors] (pole-to-pole span: 60mm)

FFG(No.2084/No.2085)

Resolution

PLC0

(2000#0)

Number of velocity pulses /

Number of position pulses,

Conversion coefficient

(No.2023 / No.2024, 2185)

AMR conversion

coefficient 1 or 2

(No.2112, 2138)

1-µm detection

0.1-µm

detection

0.1 0 1953 / 6250, 0 9375, 6 1/10 1/1

0.05 0 3906 / 12500, 0 9375, 7 1/20 1/2

[Small motors] (pole-to-pole span: 30mm)

FFG(No.2084/No.2085)

Resolution

PLC0

(2000#0)

Number of velocity pulses /

Number of position pulses,

Conversion coefficient

(No.2023 / No.2024, 2185)

AMR conversion

coefficient 1 or 2

(No.2112, 2138)

1-µm detection

0.1-µm

detection

0.1 0 1953 / 6250, 0 9375, 5 1/10 1/1

0.05 0 3906 / 12500, 0 9375, 6 1/20 1/2

* The parameter Nos. for the Series 15i are omitted. See the

previous page.

(Cautions)

If the encoder signal pitch is larger than 200 µm, various coefficients

used in the servo software may overflow to raise an alarm on invalid

parameters, because the setting for the number of velocity pulses

becomes very small.

In this case, change the corresponding parameter by referencing

Subsection 2.1.8, "Measures for Alarms on Illegal Servo Parameter

Settings."

Parameter setting procedure (3)

When a linear motor is used, the linear encoder must be installed so

that the Z phase of the linear encoder matches the origin of the

activating phase. Otherwise, the specified motor characteristics cannot

be obtained. (For details of installation positions, refer to "FANUC

LINEAR MOTOR Lis series DESCRIPTIONS (B-65382EN)".)

Procedure (3) describes the method of adjusting the activating phase

origin (AMR offset adjustment) when it is difficult to install a linear

encoder at a specified position with a specified precision.
