4.SERVO FUNCTION DETAILS B-65270EN/05

- 146 -

For Series 15i

Attenuation center

frequency [Hz]

Attenuation

bandwidth

Damping

Resonance elimination filter 2 No.2773 No.2774 No.2775

Resonance elimination filter 3 No.2776 No.2777 No.2778

Resonance elimination filter 4 No.2779 No.2780 No.2781

Resonance elimination filter 1 No.1706 No.2620 No.2772

<3> Setting for an active resonance elimination filter

The active resonance elimination filter is a function for setting the

center frequency of a resonance elimination filter to the resonance

frequency so as to maintain a high stability even when the center

frequency deviates from the actual resonance frequency. It takes effect

when:

• The resonance frequency shifts as the axis moves.

• The resonance frequency varies from one machine to another

because of a difference among the machines.

• The resonance frequency changes with time.

#7 #6 #5 #4 #3 #2 #1 #0

2683 (FS15i)

ACREF

2270 (FS30i, 16i)

ACREF(#3) The active resonance elimination filter is:

0 : Disabled

1 : Enabled

CAUTION

1 The active resonance elimination filter can be used

with the conventional specification of resonance

elimination filter 1. To use the active resonance

elimination filter, specify damping = 0 for

resonance elimination filter 1.

2 The active resonance elimination filter performs

follow-up operation over ±40 Hz with respect to a

specified center frequency.

3 The active resonance elimination filter becomes

enabled when the emergency stop is released.

4 The active resonance elimination filter does not

perform follow-up operation during acc./dec.

5 When the attenuation center frequency of

resonance elimination filter 1 is changed, the

center frequency is re-set to the specified center

frequency, and then the filter restarts follow-up

operation using this newly specified center

frequency as an initial value.
