4.SERVO FUNCTION DETAILS B-65270EN/05

- 156 -

(7) Stop time observer disable function

If the observer function is enabled, the machine may fluctuate and

become unstable when it stops. Such a fluctuation or unstable

operation can be prevented by disabling the observer function only in

the stop state.

(8) Setting parameters

<1> Function bit

#7 #6 #5 #4 #3 #2 #1 #0

1960 (FS15i)

MOVOBS

2018 (FS30i, 16i)

MOVOBS (#1) The function for disabling the observer in the stop state is:

0: Disabled

1: Enabled ← Set this value.

<2> Level at which the observer is determined as being disabled

1730 (FS15i)

Level at which the observer is determined as being disabled

2119 (FS30i, 16i)

[Unit of data] Detection unit

[Typical setting] 1 to 10

If the absolute value of the position error is less than the level at which

the observer is determined as being disabled, the observer function is

disabled.

NOTE

This parameter is also used for the stop

determination level of the function for changing the

proportional gain in the stop state.

(Usage)

Set the function bit and the level at which the observer is determined

as being disabled so that it is greater than the peak absolute value of

the oscillating position error.
