5.DETAILS OF PARAMETERS B-65270EN/05

- 372 -

#7 #6 #5 #4 #3 #2 #1 #0

1952 (FS15i)

LAXDMP

PFBSWC VCMDTM

SPPCHG SPPRLD VFBAVE TNDM

2008 (FS30i, 16i)

TNDM (#1) This bit is automatically set to 1 when bit 6 (tandem axis) of parameter

No. 1817 is set to 1. (In the Series 15i, this bit is kept at 0.)This bit

cannot be set directly.

VFBAVE (#2) 1: Enables the velocity feedback average function. (Usually, set this

bit to 1. Set this parameter for the main axis only.)

[Reference item] Section 4.16 and Subsection 4.18.3

SPPRLD (#3) 1: Enables the full preload function. (Set this parameter for the main

axis only.)

[Reference item] Subsection 4.18.6

SPPCHG (#4) The motor output torque polarities are as follows:

0: Outputs only the positive polarity to the main axis, and outputs

only the negative polarity to the sub-axis.

1: Outputs only the negative polarity to the main axis, and outputs

only the positive polarity to the sub-axis. (Set this parameter for

the main axis only.)

[Reference item] Subsection 4.18.6

VCMDTM (#5) 1: Enables velocity command tandem control.

(Set this parameter for the main axis only.)

PFBSWC (#6) 1: Switches position feedback according to the direction of a torque

command. (Set this parameter for the main axis only.)

[Reference item] Subsection 4.18.7

LAXDMP (#7) 0: Enables damping compensation for the sub-axis only.

1: Enables damping compensation with both the main axis and

sub-axis.Usually, set this bit to 1. (Set this parameter for the main

axis only.)

[Reference item] Subsection 4.18.2

#7 #6 #5 #4 #3 #2 #1 #0

1953 (FS15i)

BLST BLCU ANALOG ADBL SERD

2009 (FS30i, 16i)

SERD (#0) The serial feedback dummy function is:

0: Not used.

1: Used .

[Reference item] Subsection 4.9.1

ADBL (#2) The new backlash acceleration function is:

0: Not used.

1: Used .

[Related parameters] 1860 (15i), 2048 (16i etc.), 1980 (15i), 2087 (16i etc.)
