4.SERVO FUNCTION DETAILS B-65270EN/05

- 270 -

4.13 FUNCTION FOR OBTAINING CURRENT OFFSETS AT

EMERGENCY STOP

(1) Overview

A current offset is an offset value arising from an analog offset

voltage associated with an current detector. If such an offset value is

not obtained correctly, the feedback current of the motor is adversely

affected, resulting in slight irregularities in the rotation of the motor

(four components per motor revolution).

At present, a current offset is obtained once when the power to the NC

is turned on as standard. The offset value varies, depending on the

temperature of the current detector. Use this function to cope with

such variations in time.

(2) Series and editions of applicable servo software

(Series 30i,31i,32i)

Series 90D0/A(01) and subsequent editions

Series 90E0/A(01) and subsequent editions

(Series 15i-B,16i-B,18i-B,21i-B,0i-B,0i Mate-B,Power Mate i)

Series 9096/A(01) and subsequent editions

Series 90B0/A(01) and subsequent editions

Series 90B1/A(01) and subsequent editions

Series 90B6/A(01) and subsequent editions

(Series 0i-C,0i Mate-C,20i-B)

Series 90B5/A(01) and subsequent editions

(3) Setting parameters

#7 #6 #5 #4 #3 #2 #1 #0

1741 (FS15i)

CROFS

2201 (FS30i, 16i)

CROFS (#0) 1: Enables the current offset to be obtained upon the occurrence of an

emergency stop.

If the above setting is made, the current offset is obtained again during

an emergency stop.
