4.SERVO FUNCTION DETAILS B-65270EN/05

- 296 -

Overflow occurred.

Set the following bits:

Bit 6 of No. 1740 = 1 (Series 15

)

Bit 6 of No. 2200 = 1 (Series 30

, 16

and so on)

Not larger than 32767

Overflow not produced

Not larger than 32767

Larger than 32767

B = A × (velocity loop gain override [%]

(*1)

)/100

larger than 32767?

|PK2V parameter|

(load inertia ratio + 256)

2000

(Number of velocity pulses)

larger than 32767?

Fig. 4.14.1(g) PK2V overflow check

CAUTION

In the flowchart above, the velocity loop gain

override is represented by one of the following

parameters:

Velocity gain magnification when high-speed HRV

current control is enabled

→ (No. 2335 for Series 30i, 16i, and so on or No.

2748 for Series 15i)

Velocity gain override when the cutting feed/rapid

traverse switchable velocity loop gain function is

enabled

→ (No. 2107 for Series 30i, 16i, and so on or No.

1700 for Series 15i)
