FAPT Ladder for PC Operators manual Page 306

Operators manual
FAPT LADDER OPERATOR’S
SUPPLEMENTARY MANUAL
(FOR PERSONAL COMPUTER)
01 98.06.22 Hanaoka Additioanl 3.5-inch FD version B-66131E/05-5
EDIT DATE DESIG.
DESCRIPTION
3/8
TITLE
DRAW.NO.
SHEET
CUST.
1. Outline
The following specification and function have been added to the PMC programming
software “FAPT LADDER” for personal computer.
・ The system of 3.5-inch FD version .
・ Working under a Command Prompt of a full screen of Windows NT 4.0.
This manual is a supplementary manual for these additional functions.
Other points (existing functions and operation, etc.) are described in the following manual.
Name of Manual Spec.No. Reference Items
FAPT LADDER
OPERATOR’S MANUAL
B-66131E Existing functions and
operation for FAPT
LADDER
2. Applied Software
The additional functions described herein apply to the following software.
・ FAPT LADDER for IBM-PC/AT series (3.5-inch FD)
Software Series Version
PMC-L/M/P system A08B-9201-J500#EN07 08.0
PMC-N/NA system A08B-9201-J501#EN07 07.0
PMC-SA/SB/SC/NB/PA/QC system A08B-9201-J502#EN07 09.0
PMC-L module A08B-9201-J600#EN07 06.0
PMC-M module A08B-9201-J601#EN07 07.0
PMC-M(MMC) module A08B-9201-J602#EN07 06.0
PMC-SA/PA module A08B-9201-J603#EN07 05.3
PMC-SB/SC module A08B-9201-J604#EN07 07.1
PMC-QC module A08B-9201-J605#EN07 02.3
PMC-NB module A08B-9201-J606#EN07 03.1
・ FAPT LADDER for PC98 series (3.5-inch FD) (Note)
Software Series Version
PMC-L/M/P system A08B-9200-J500#JP07 06.3
PMC-N/NA system A08B-9200-J501#JP07 06.3
PMC-SA/SB/SC/NB/PA/QC system A08B-9200-J502#JP07 08.9
PMC-L module A08B-9200-J600#JP07 06.0
PMC-M module A08B-9200-J601#JP07 07.0
PMC-M(MMC) module A08B-9200-J602#JP07 06.0
PMC-SA/PA module A08B-9200-J603#JP07 05.3
PMC-SB/SC module A08B-9200-J604#JP07 07.1
PMC-QC module A08B-9200-J605#JP07 02.3
PMC-NB module A08B-9200-J606#JP07 03.1
(Note) These FD are the 1.44MB format FD. If the machine can not read the 1.44MB
format FD, these FD are not available for the machine.
3. Addition of system of 3.5-inch FD version
The 3.5-inch FD version has been added to the PMC programming software “FAPT
